Product Details:
|
| Name: | C9200-24T-E | Model: | C9200-24T-E - Cisco Switch Catalyst 9200 |
|---|---|---|---|
| Detail: | Catalyst 9200 24-port Data Switch, Network Essentials | Availability: | In Stock |
| Condition: | New Factory Sealed | Warranty: | 3 Years |
| Fans: | FRU Redundant | Software: | Network Essentials |
| DRAM: | 4 GB | Flash: | 4 GB |
| Highlight: | 24 Port POE Ethernet Switch,C9200 POE Ethernet Switch,Cisco POE Data Network Switch |
||
C9200-24T-E Overview
C9200-24T-E is the Catalyst 9200 24-port Data Switch, with Network Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.
Quick Spec
| Model | C9200-24T-E |
| Downlinks total 10/100/1000 or PoE+ copper ports | 24 ports data |
| Uplink configuration | Modular uplink options |
| Default primary AC power supply | PWR-C6-125WAC |
| Fans | FRU redundant |
| Software | Network Essentials |
| Stacking bandwidth | 160 Gbps |
| DRAM | 4 GB |
| Flash | 4 GB |
| Switching capacity | 128 Gbps |
| Forwarding rate | 190.4 Mpps |
| Chassis Dimensions |
1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm |
Catalyst 9200 series provides these highlights:
● Up to 48 ports of full Power over Ethernet Plus (PoE+) capability
● Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
● Flexible downlink options with data or PoE+
● Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
● UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
● Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
● Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
● Advanced network monitoring using Full Flexible NetFlow
● Cisco Software-Defined Access (SD-Access):
◦ Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE)
◦ Network assurance and improved resolution time through Cisco DNA Center™
● Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
● Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry
● ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries
Compare to Similar Items
| Product number | Product description |
| C9200-24T-A | Catalyst 9200 24-port Data Switch, Network Advantage |
| C9200-24T-E | Catalyst 9200 24-port Data Switch, Network Essentials |
| C9200-24P-A | Catalyst 9200 24-port PoE+ Switch, Network Advantage |
| C9200-24P-E | Catalyst 9200 24-port PoE+ Switch. Network Essentials |
